Mesh or grid can be in 3- dimension and 2-dimension. Meshing has applications in the fields of geography, designing, computational fluid dynamics. And many more places. The two-dimensional meshing includes simple polygon, polygon with holes, multiple domain and curved domain. In three dimensions there are three types of inputs. The responsive grid focuses on consistent spacing widths, rather than column width. Material Design margins and columns follow an 8px square baseline grid. The spacing property is an integer between 0 and 10 inclusive.

Description

Pointwise generates structured, unstructured, hybrid, overset, voxel, and high-order grids. The element types it makes include triangles, quadrilaterals, tetrahedra, pyramids, prisms andhexahedra. Pointwise divides the overall computational space into one or more sub-regions called blocks.

Pointwise can be used to generate both 2D and 3D blocks. A 2D block consists entirely of surface cells while a 3D block contains entirely volumetriccells. All blocks in the same grid must either be 2D or 3D; you cannot combine blocks of differing dimensionality in the same grid.
